Hammer crusher that is opt for both dry and wet crushing of medium, hard and brittle materials. Hammer mills are used for grinding almost all types of free flowing materials. It operates on the principle that most materials will grind or crush upon impact with the hammers. The material is ground by repeated contact with hammers, contact with the walls of the grinding chamber, and particle to particle contact. The material remains in the grinding chamber until it is suitably sized to pass through the perforated screen that covers the bottom half of the grinding chamber. Hammers are made up of MS, Mn, EN flats or alloy steel which are hardened up to required hardness.
|MODEL||ROTOR DIA. (mm)||ROTOR WIDTH (mm)||POWER* (HP)||CAPACITY* (KGPH)|
|RTI-1218HC||300||450||5 - 7.5||100 - 300|
|RTI-1224HC||300||600||15 - 20||300 - 800|
|RTI-1824HC||450||600||30 - 40||1000 - 1500|
|RTI-2430HC||600||750||60 - 75||2000 - 2500|
|RTI-2440HC||600||1000||75 - 100||3000 - 5000|
