Bucket Wheel Washer With Dewatering Screen
R-TECHNO bucket wheel washer is applied for washing, grading and dehydrating at construction sites, sand plants. It features of high degree cleaning up, reasonable structure, large capacity, low power & water consumption, small loss of the sands during aggregate & sand washing process, especially for that the drive parts of the sand washing machine are separated from water and sands. So it has lower failure rate than the usual sand washing machine.
Salient Features:
- Dewatering screen available in single and dual sand washing model
- Upward inclination for better dewatering and surge capacity
- Better stockpile management with shorter inventory cycle and less water around stockpiles
- Control of gradation with recycle systems
- Huck bolted, cross beam construction for rigidity and ease of maintenance
- Heavy duty PU(polyurethane) screen media and attachment system
| MODEL | DRIVE MOTOR* (HP) | DEWATERING SCREEN SIZE (mm) | VIBRATING MOTOR* (HP) | CAPACITY* (TPH) |
|---|---|---|---|---|
| RTI-60BW | 5 | 1800 x 900 | 1*2 | 60 |
| RTI-80BW | 7.5 | 2100 x 900 | 1.5*2 | 80 |
| RTI-100BW | 10 | 2100 x 1200 | 2*2 | 100 |
| RTI-120BW | 15 | 2100 x 1200 | 2*2 | 120 |
| RTI-150BW | 20 | 3000 x 1200 | 3*2 | 150 |
| RTI-60BWD | 5 | 1800 x 1200 | 1.5*2 | 60 |
| RTI-80BWD | 7.5 | 2100 x 1200 | 1.5*2 | 80 |
| RTI-100BWD | 10 | 2400 x 1200 | 2*2 | 100 |
| RTI-120BWD | 15 | 2400 x 1500 | 3*2 | 120 |
